Reagent for oil extraction BMG-C4
BMG-C4, which is used to increase the efficiency of the extraction of vegetable oils during the process of their production, has the ability to separate oils from solid particles.
After crushing/pressing the fruits/seeds of vegetable oil crops during the process of oil extraction in the aqueous phase, as well as during the stages of settling and centrifugation, the goal is to maximize the separation of the oil sandwiched between the particles of the crushed culture. BMG-C4 can be used at each of those stages.
Reagent for Oil Extraction BMG-C4 forming submicron films around oil droplets and on the surfaces of fruit solid particles and by this helping to release oil to float up to the surface.
Unlike other Biomicrogel® modifications used as a sorbent, flocculant, or flocculating agent, where the strength of films (microcapsules) is critical and must be maintained for a long period of time, in this case it is important to ensure just the short-term presence of such films on the surface of the solid particles, ensuring the oil is separated from the solids and the oil then floats to the surface of the water. After the process is completed, BMG-C4 remains in the water phase and in the solids.
Reagent for Oil Extraction BMG-C4 forming submicron films around oil droplets and on the surfaces of fruit solid particles and by this helping to release oil to float up to the surface.
Unlike other Biomicrogel® modifications used as a sorbent, flocculant, or flocculating agent, where the strength of films (microcapsules) is critical and must be maintained for a long period of time, in this case it is important to ensure just the short-term presence of such films on the surface of the solid particles, ensuring the oil is separated from the solids and the oil then floats to the surface of the water. After the process is completed, BMG-C4 remains in the water phase and in the solids.
BMG-С4 is used in the form of a 3% solution.
In order to prepare the BMG-C4 solution for use, it is necessary to use the special BMG PDS series preparation and dosing equipment while following the instruction manual for BMG-C4
BMG-С4 is supplied as powder.
It is packed in 25kg polypropylene bags; the bags are then placed on pallets. One pallet carries 20 bags, which is 500 kg of product.
To avoid hydrolysis or the growth of bacteria and fungi, resulting in a deterioration of the solution, use the BMG-С4 solution within 7 days of its preparation.
BMG-C4 is stored in the manufacturer’s package in ventilated warehouse premises protected from direct sunlight at a relative humidity of no more than 70% at a temperature not exceeding 37°C in conditions that exclude dust penetration and precipitation. The guaranteed shelf life of the packaged product is 24 months as from the date of production.
When the solution is prepared, it creates an environment for the growth of airborne or aquatic bacteria and fungi. Always add a biocide in storage areas where this process is taking place.
It is recommended to use isothiazoline-based biocides in the proportion of 700 ppm of agent per volume of water. Equipment for the preparation of the BMG-С4 treatment solution as well as any containers for its storage and any pipelines used should be pre-flushed and disinfected.
BMG-С4 shall be disposed of in accordance with effective legislation.
This station for the preparation and dosing of the Biomicrogel® BMG-C4 oil extraction additive supports the following modes of operation:
- Automatic:
In manual mode, after the Biomicrogel® BMG-C4 oil extraction reagent solution is prepared, the station and the dosing pump are controlled by the turn on/off signal from the main transfer pump. - Manual:
In manual mode, after the Biomicrogel® BMG-C4 oil extraction reagent is prepared, the station and the dosing pump remain under the real-time control of a human operator.
The station for the preparation and dosing of the Biomicrogel® BMG-C4 oil extraction additive is shipped as a semi-knocked-down kit. The assembly and commissioning of the station is carried out locally by the customer under the supervision of representatives from SPC BioMiсroGel LLC. Prior to installation, preparatory works should be carried out by the customer to get the site ready for the permanent operation of the unit.
